JYF Muti-Function Single Head Hot Filling Line

Widely applicable, can be applied to most oily fluid filling, especially suitable for liquids and pastes such as lipstick, lipstick, liquid foundation and oils, as well as cold filling and hot filling of ordinary grease and liquids.

Dimension : 3100x1220x1710mm
Voltage : 1P 220V
Power : 4.5KW
Working pressure : 0.5-0.8 MPa
Company:
Email:
Message:


Widely applicable, can be applied to most oily fluid filling, especially suitable for liquids and pastes such as lipstick, lipstick, liquid foundation and oils, as well as cold filling and hot filling of ordinary grease and liquids

Adopts servo motor to drive the piston for filling, which is more accurate. Equipment accuracy error is less than 2%


Equipped with our specially designed thermal insulation system, without oil circulation system, and can realize the function of uniform constant temperature filling of all parts. At the same time, the machine adopts the filling nozzle plugging technology, which can realize the function of large-dose filling of hot-filled products.


This machine can replace material cylinders of different volumes, and adopts a quick-release design, which is clear and convenient.


Industrial hot air gun imported from Switzerland, reliable quality and long life; (customized)


This machine adopts servo motor to realize the way of filling and rising.


Flexible and strong. This machine is suitable for the quick production change function of different specifications of packaging materials, and adopts a modular design, which can quickly disassemble the valve body cleaning function. (Disassembly time for cleaning is about 1-2 minutes)



Model

JYF

Multi-Function Single Head Hot Filling Line


Voltage

1P 220V

Currency

20A


Output

5-30pcs/min

Output

300-1800pcs/hour


Power

4.5KW

Air pressure

0.5-0.8 MPa


Precision

50g piston cylinder ±0.1g100g piston cylinder±0.15g

Filling Scope

50g piston cylinder 5-50g

100g piston cylinder 10-100g


Dimension

3100x1220x1710mm
