Three roll miller is used for milling high viscosity materials in the field of paint, printing ink , colors, cosmetic materials, soaps.
| Dimension : | 980×750×915mm ( L x W x H ) |
| Voltage : | |
| Power : | 2.2kw |
| Working pressure : |
Three roll miller is used for milling high viscosity materials in the field of paint, printing ink , colors, cosmetic materials, soaps.Main body is welde by advanced steel plate, driven mode is adopting chain wheel or gear oil dipping type. Operational handwheel is adopting gear driven,also it has features of low noise, easy operation, outer nice .
| Model | JSG6 | JSG10 | JSG12 | JSG16 | ||
| Roller diameter | cm | 15 | 26 | 31.5 | 40.6 | |
| Length | cm | 30 | 67.5 | 75.5 | 81 | |
Roller Speed | Slow | r/min | 34 | 22 | 22 | 22 |
| Mid | r/min | 78 | 66 | 66 | 66 | |
| Fast | r/min | 181 | 198 | 198 | 198 | |
| Power | kw | 2.2 | 7.5 | 11 | 15 | |
| Outer dimension | cm | 98x75x91.5 | 120x100x110 | 256x173.5x151 | 256x203.5x152.5 | |
| Weight | kg | 500 | 2000 | 2800 | 5300 | |
